BRAND | Groschopp |
Product | Typ: IGLU 80-60 + Typ: VE31-G-R-5 |
Internal code | ONR4603015 |
Technical specification | VARIOUS AC ASYNCHRONOUS GEAR MOTOR 400/230 V, 50 Hz, 2760 U, 180 W, B14, IP65, 0.64/1.10 amps, Energy efficiency class: IE2 VSD - frequency optimized 45-100 Hz, nmax. 6000 U, 270 W, fmin. 5 Hz, motor wound according to WK 17928-01-04, Left/right rotation according to circuit diagram S61-0701-30, motor with phase isolation, motor UR/UL conform, motor with terminal box AK2 and 6-pin clipboard, circuit diagram in the terminal box, Motor with heat limiter 140°C as opener Connections on WAGO terminal mounted with: SIMPLE WORM GEAR Tipo: VE31-G-R-5 i= 38:1 n2= 72 rpm, M2= 18.6 Nm Operating factor fB= 0.48 large flange: Ø 110 mm, flange and shaft on the right Gear shaft: Ø 12 g6 x 30 mm long with groove+feather key A4x4x20 mm according to DIN 6885 sheet1 RAL 5002 paint - ultramarine blue Weight: 4.65 kg terminal box location: 34 Transmission installation: 1 |
Discover the superior quality and performance of the Groschopp Typ: IGLU 80-60 + Typ: VE31-G-R-5 with Onrion LLC in Argentina . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Typ: IGLU 80-60 + Typ: VE31-G-R-5 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Typ: IGLU 80-60 + Typ: VE31-G-R-5 :
At Onrion LLC , we offer the Typ: IGLU 80-60 + Typ: VE31-G-R-5 at competitive prices and with the fastest delivery times across Argentina . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the Typ: IGLU 80-60 + Typ: VE31-G-R-5 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Groschopp products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
MOTOR
ENGINE
WELLENDICHTRING, Sach-Nr.: 2216043
GLEICHSTROM-GETRIEBE-MOTOR
Forcing özllk's technical information
NR. 8739851 WK 1695501 155 W 1400 REV/MIN
geared motor
motor
NR:10669940 WK 1782201 IEK 90-60 IP 00
50-60HZ KB400W 2800-3400min-1
electronic engine 2800RPM
PM1 48 – 25 ; 24VDC; 12 W; 3000 D/D
DC Motor
PM1 48-25 obsolete, replaced by Typ G321 (PM1 85-40)
DC POWER TRANSMISSION ENGINE
3000 U, 12W, B14, IP54, wound motor according to WK 1,054,702 mounted with spur gear
(GLEICHSTROM-GETRIEBE-MOTOR24 V DC, 3000 U, 18 W, B3, IP44, Motor gewickelt to WK 1083502, Links-/Rechtslauf to Schaltbid S 21-0001-01 for E1-Getriebeanbau)
motor Torque 7,8. 32 watts 0,25 amp
DC-gear motor
