| BRAND | Uwt |
| Product | RN3002: B011EA7Z7A + 32 X |
| Description | Level probe |
| Internal code | ONR4490405 |
| Technical specification | Pos.10: Type [B] RN 3002 Pos.20: Certificate [0] CE Pos.30: Process temperature [1] max. +80°C (176°F) Pos.40: Process overpressure [1] max. 0,8 bar (11.60 psi) Pos.50: Power supply [E] 24 V DC 2.5 W Pos.60: Process connection [A] Thread G 1½', DIN 228 Pos.70: Material process connection [7] stainless steel 1.4404 (316L) Pos.80: Length of extension L [Z] special length special length (in mm): 340 Pos.90: Material of extension L [7] stainless steel 1.4404 (316L) Pos.100: Measuring vane [A] boot-shaped 40 x 98 mm (1.57 x 3.86') stainless steel, for 1½' socket Pos.200: Local Certificates [0] without Pos.320: Bearing at tube end [X] with Pos.330: Extension / flange welded [0] without |
Please Contact Us to Order to offer competitive prices and delivery time for Uwt - RN3002: B011EA7Z7A + 32 X Level probe number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Argentina Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
level control
(If you want 24 VDC, 220 VAC, if you want) Stainless, 80 deg C, 0.8 bar, 1.5 inch connection is 1000 mm, double flag, bearing exit
Rotating Paddle Level Limit Switch RN3002 BO32AF3Z3B-750mm
RN3002BS011AL3Z3A-L=600MM+POS.32
1SDA013509R1 250A
ROTONIVO ROTATING PADDLE SWITCH
WGRN3 LGRN3E 230 V AC
p:= 0,5 - 0,8 bar L:= 165mm
ROTONIVO ROTATING PADDLE SWITCH E = PIPE HORIZONTAL W = ATEX ZONE 20/21 DUST IGNITION PROOF 1 = MAX TEMP 176*F (80*C) 1 = MAX PRESS 11.6 PSI (0.8 BAR) F = 24V DC / 22...230V AC universal voltage Motor Speed:1/min A = G 1.5" THREAD PROCESS CONNECTION 1 = Aluminium PROCESS CONNECTION Q = SHAFT LENGTH 250 mm (9.84") 3 = STAINLESS STEEL SHAFT A = BOOT-SHAPED VANE 40 x 98mm (1.57 x 3.86")
ROTONIVO ROTATING PADDLE SWITCH E = PIPE HORIZONTAL W = ATEX ZONE 20/21 DUST IGNITION PROOF 1 = MAX TEMP 176*F (80*C) 1 = MAX PRESS 11.6 PSI (0.8 BAR) W = 24 VDC POWER SUPPLY, MOTOR SPEED 5 RPM A = G 1.5" THREAD PROCESS CONNECTION 3 = SS PROCESS CONNECTION Z = SHAFT LENGTH (500MM) 3 = STAINLESS STEEL SHAFT A = BOOT-SHAPED VANE FOR 1/5" SOCKET
Rotary level switch ·Atex Version ½ D Zone 20/21 ·Power supply “Universal voltage” 230Vac, 115Vac 24Vdc ·Output SPDT with 20 sec. Delay time ·Sensibility adjustment ( 3 step ) Process connection G 1 ½” in SS ·Reinforced pipi with berings and dust protection ·Lenght 1000 mm Vane 40x98 mm ·Diagnostic self control ·Sliding sleeve included
