| BRAND | Interroll |
| Product | RD-11EDNAAKAC RL: 290;AGL: 320 |
| Internal code | ONR573120 |
| Weight | 1 |
| Technical specification | 1100 Series Light Conveyor Roller/Redesign ReDesign RL - roll length 290.0 mm/ EL - installation length: 300.0 mm AGL - total axle length 320.0 mm Bearing type cone stainless steel greased Tube material stainless steel Outer pipe diameter 50.0 mm/ pipe wall thickness 1.5 mm Axle material stainless steel/axle diameter 10.0 mm Left side of spring 1 spring Axle overhang left 10.0 mm/axle overhang right 10.0 mm Axle design length 1 left 0.0 mm/axle design length 1 right 0.0 mm Axle design length 2 left 0.0 mm/axle design length 2 right 0.0 mm |
Discover the superior quality and performance of the Interroll RD-11EDNAAKAC RL: 290;AGL: 320 with Onrion LLC in Argentina . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The RD-11EDNAAKAC RL: 290;AGL: 320 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of RD-11EDNAAKAC RL: 290;AGL: 320 :
At Onrion LLC , we offer the RD-11EDNAAKAC RL: 290;AGL: 320 at competitive prices and with the fastest delivery times across Argentina . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the RD-11EDNAAKAC RL: 290;AGL: 320 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Interroll products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
3.5XQ.HF9.N91 DİMENSİONS FOR 2 STEEL SPROCKETS 1/2 Z:14
CONVEYOR 90 ° BACK BAND ROLL
Print: 50 x 1.5 Z11 EL: 650
tapered fixed drive conveyor roller series
Heavy-Duty Conveyor Roller Conveyor Rolle
Steel Ball Transfer Unit
MI-DL0113 DL1133-AAA0AD0ABJSC-295mm
Trommelmotor 113S
MC-MOTOR
BT100; 37: 1; SI; M12; PIPE; SI; 50; x 1.5; BEAD: 2; d 38.4; SB; IG M8; ReDesign
CONTROL CARD INTERROLL 04770600
BU 40 L=1976MM-ROLLCHEN PP 2REIHIG 8MM
Role Type rolls PP 2 row 8mm Total length 1976.0 mm First position roll 26.0 mm Pitch 52.0 mm Position last role 26.0mm Distance length 1924.0 mm Number of rolls 38
road roller with the necessary mounting dimensions.
BU40 L=520MM ROLLCHEN PP 2REIHIG 8MM
Castor Rail Series caster kit BU40 BU Role Selection mounted Role Type rolls PP 2 row 8mm Overall length 520.0 mm First position roll 26.0 mm Pitch 52.0 mm Position last role 26.0mm Displacement Length 468.0 mm Number of rolls 10
BU40 L=572MM-ROLLCHEN PP 2REIHIG 8MM
Castor Rail Series caster kit BU40 BU Role Selection mounted Role Type rolls PP 2 row 8mm Overall length 572.0 mm First position roll 26.0 mm Pitch 52.0 mm Position last role 26.0mm Displacement Length 520.0 mm Number of rolls 11
drum motor
Product name 113S UL approval ULZertifiziert Degree of protection IP 66 SL tube length 490.0 mm 512.0 mm Stirnflächenweitezw.Deckeln EL / LW / BF Installation length 518.0 mm AGL axis total length 558.0 mm Power 180 W winding poles 4 Torque [Nm] 23.8 tensile force 421 N Gear ratio 26.84 GeschwindigkeitbeiFrequenz 1 0.367 m / s Frequency 1 Hz winding 60 phase number 3 high voltage 480 V low voltage 0 V GeschwindigkeitbeiFrequenz 2 0.306 m / s 2 frequency 50 Hz 2 high voltage 440 V low voltage V 2 0 maximum outer diameter 113.3 mm Tube shape sonderballig / pyramidal Steel pipe material: St37-2 / AISI1015
MI-DMI AC138I-LCD0AA0E6LGA-600m
drum motor
Series 1700
Series 1700
RD-17XBJQENAE RL: 240;AGL: 250
Series 1700 Universal Conveyor Roller Redesign Redesign RL - Roll length 240.0 mm EL - Installation length: 250.0 mm AGL - of shaft 250.0 mm Bearing Prz.Lager steel blank fat 2RZ Galvanized steel pipe material Tube outside diameter 50.0 mm wall thickness, 3.0 mm Axle material steel blank axle diameter 14.0 mm Shaft lengths links 0,0 mm Shaft lengths at right 0.0mm Axis version 1 internal thread on both sides M8x15 Achsausführungslänge 1 Links 0.0 mm Achsausführungslänge one right 0.0mm Achsausführungslänge two links 0,0 mm 2 Achsausführungslänge right 0.0mm
RD-17XBJQENAE RL: 540;AGL: 550
Series 1700 Universal Conveyor Roller Redesign Redesign RL - Roll length 540.0 mm EL - Installation length: 550.0 mm AGL - of shaft 550.0 mm Bearing Prz.Lager steel blank fat 2RZ Galvanized steel pipe material Tube outside diameter 50.0 mm wall thickness, 3.0 mm Axle material steel blank axle diameter 14.0 mm Shaft lengths links 0,0 mm Shaft lengths at right 0.0mm Axis version 1 internal thread on both sides M8x15 Achsausführungslänge 1 Links 0.0 mm Achsausführungslänge one right 0.0mm Achsausführungslänge two links 0,0 mm 2 Achsausführungslänge right 0.0mm
RD-35NGJABN90 RL: 360;AGL: 400
