BRAND	Hioki
Product	MR8870
Description	MEMORY HiCORDER
Internal code	ONR796506
Weight	1
Technical specification	Number of channels 2 analog channels + 4 logic channels (standard) Note: Isolated analog channels, isolated input and frame, logic has common GND Measurement ranges 10 mV to 50 V/div (10 div full-scale), 12 ranges, Resolution: 1/100 of range Max. rated voltage Between terminals: 400 VDC, Between terminal to earth: 300 VAC, DC CAT II Frequency characteristics DC to 50 kHz (-3 dB) Time axis (Memory mode) 100 µs to 5 min/div, 20 ranges,at 100 points/div resolution, three steps of time-axis magnification from ×2 to ×10, and 9 steps of time-axis compression from ×1/2 to ×1/1,000 Recording intervals (RMS mode) 1 ms to 1 min., 16 settings, sampling period: 200 μs (fixed) (for AC voltage/current, 1,000 RMS values/sec.), envelope mode always on Note: Only the maximum value and minimum value for each recording interval are recorded. Measurement functions Memory recorder (high speed recording), RMS recorder (50/60 Hz, DC only) Memory capacity 12-bits × 2M-words/ch (1 word = 2 bytes) Removable storage CF card TYPE I slot ×1 (Up to 2 GB) Display 4.3-inch WQVGA-TFT color LCD (480 × 272 dots) Displayable languages English, Japanese Interfaces USB 2.0 mini-B receptacle ×1, Functionality: Connect the instrument to a PC to send files on the CF card to the PC. The instrument cannot be controlled from a PC. Printer N/A Power supply AC Adapter Z1005: 100 to 240 VAC (50/60 Hz) , 30 VA max. (when using the AC adapter and charging the 9780 with the instrument) Battery Pack 9780: 3 VA, continuous operating time of approx. 2 hr. (25°C reference value; when used with the Z1005, the Z1005 takes priority), charging time of 200 min. using the AC adapter (25°C reference value) (option) External DC power: 10 to 16 V, 10 VA max. (connection cord of 3 m or less is available by special-order) Dimensions and mass 176 mm (6.93 in)W × 101 mm (3.98 in)H × 41 mm (1.61 in)D, 600 g (21.2 oz) (with the Battery pack 9780 installed)

Please Contact Us to Order to offer competitive prices and delivery time for Hioki - MR8870 MEMORY HiCORDER number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Argentina Industrial products Market.
