BRAND | Thermokon |
Product | Art.-Nr. 659093 |
Description | Temperature and humidity sensor |
Internal code | ONR4619003 |
Custom code | 90258040 |
Technical specification | FTK+ 140 RS485 Modbus Channel sensor temperature, humidity — Modbus|0.. 5/10 V Usgang voltage: 2x 0.. 10 V or 0.. 5 V, adjustable via jumper, live zero configuration via app or uConfig, min. load 10 kO Network technology: RS485 Modbus Operating temperature range: -20.. +70 °C, temperature accuracy: ±0.3 K (typical at 21 °C) in Standard measuring range, offset setting via app or UConfig Humidity measuring range: 0..100% rH without condensation, 0.. 85 kJ/kg enthalpy, 0.. 50 | 0.. 80 g/m³ absolute humidity, 0.. +50 | -20.. +80 °C dew point, optionally configurable Humidity accuracy: ± 2% between 10..90% rH (typically at 21 °C), offset setting via app or uConfig Power supply: 15.. 35 V = SELV, 19.. 29 V ~ SELV Connection: removable M25 cable entry with 4-way cable entry for cables with max. Ø=7 mm, detachable plug-in terminal, max. 2.5 mm², BUS max. 1.5 mm² Medium wetted material: sensor tube, PA6, with filter stainless steel wire mesh, black, Ø=19.5 mm, Installation length: 140 mm, housing: USE-M, impact-resistant and shatter-proof housing with hinged cover, PC, Colour: pure white, protection class: IP65 Scope of delivery: incl. mounting flange, incl. mounting kit (screws and accessories) Notes: flow rate max. 12 m/s |
Discover the superior quality and performance of the Thermokon Art.-Nr. 659093 with Onrion LLC in Argentina . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Art.-Nr. 659093 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Art.-Nr. 659093 :
At Onrion LLC , we offer the Art.-Nr. 659093 at competitive prices and with the fastest delivery times across Argentina . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the Art.-Nr. 659093 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Thermokon products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
