BRAND | Thermokon |
Product | DPA2500+ VV MultiRange |
Description | differential dr measurement pressure, vol — 0..5/10 V |
Internal code | ONR4291695 |
Custom code | 90262020 |
Technical specification | 659369 output: 2x 0.. 10 V = (differential pressure and volumetric flow) Measuring range differential pressure ፦100.. +100 | 0.. +100 | 0.. +250 | 0.. +500 | 0.. +1000 | 0.. +1500 | 0.. +2000 | 0.. +2500 Pa (default: 0.. +2500 Pa), adjustable on the device Measuring range volume flow: 0.. +750.000 m³/h, adjustable via Thermocon UseApp Measurement units: pressure in Pa or InchWC, volume flow in m³/h or cfm Pressure accuracy: ±5 Pa at measuring range500 <500 Pa, ±10 Pa bei Messbereich > Pa Power supply: 15.. 35 V = or 19.. 29 V ~ Impact and shatterproof housing USE-L with hinged lid (PC, pure white, IP65) Removable cable entry (M20 flex, replaceable) and removable plug terminal (max. 2.5 mm²), Output protection circuit (reverse polarity proof) screwing on level ground, prepared for latent mounting on standard DIN rail TS35 (35x7.5 mm) Includes mounting base, fixing screws, 2 m PVC connection hose and pressure connection set |
Discover the superior quality and performance of the Thermokon DPA2500+ VV MultiRange with Onrion LLC in Argentina . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DPA2500+ VV MultiRange is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DPA2500+ VV MultiRange :
At Onrion LLC , we offer the DPA2500+ VV MultiRange at competitive prices and with the fastest delivery times across Argentina . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DPA2500+ VV MultiRange ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Thermokon products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
