| BRAND | Bd Sensors |
| Product | DMP 331P |
| Description | Industrial Pressure Transmitter |
| Internal code | ONR3389126 |
| Weight | 0.2 |
| Technical specification | Code: 500-2501-1-3-100-Z00-1-1-2-000 Device type: DMP 331P Measurement variable: relative Input code: 0... 2.5 bar El. Output: 4... 20 mA/2-wire Supply: 8... 32 VDC Accuracy: 0.35% FSO IEC Supply +: 1 Supply -: 2 Screen: Grounding Protection class: IP65 Mech Connection: G 1/2" flush with the front, DIN 3852 Separating membrane: stainless steel 1.4435 (316L) Seal: FKM Filling liquid: Food-grade oil Special design: Standard membrane position: membrane downwards Calibration temperature: 20 °C Type plate: BDS GmbH Type plate - Position: Standard El. Connection: plug and cable socket ISO 4400 |
Please Contact Us to Order to offer competitive prices and delivery time for Bd Sensors - DMP 331P Industrial Pressure Transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Argentina Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
