BRAND | Electro Adda |
Product | ART01737/ FCA 71 B-2 / HE B5 / PTC |
Description | AC three-phase motor |
Internal code | ONR4486545 |
Custom code | 85015100 |
Technical specification | Engine size: IEC 71 Motor power: 0.55 kW Motor pins: 2# Motor voltage: 3 x 230\ 400 V 10%, 50 Hz 3 x 277\ 480 V, 10%, 60 Hz Engine speed: 2745 rpm Rated motor current: 2.27/1.31 A Efficiency class: IE2 Power factor: 74.1% at 4/4 load cos phi: 0.82 Degree of protection: IP 55 Insulation class: F Motor flange: IEC 71 B5 Motor shaft: 14k6 x 30 mm Installation height: <= 1000 m above sea level Ambient temperature: -20°C to +40°C Colour: RAL 7030 Terminal box position: 1\ I Casing:aluminum Additional equipment: PTC = 3 built-in PTC thermistor sensors |
Please Contact Us to Order to offer competitive prices and delivery time for Electro Adda - ART01737/ FCA 71 B-2 / HE B5 / PTC AC three-phase motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Argentina Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
