| BRAND | Buschjost |
| Product | 8648800.9504.12049 |
| Description | 2/2-way solenoid valve |
| Internal code | ONR4600906 |
| Technical specification | type piston valve Force-controlled control DN65 connection flanges pressure stage PN 16 flange version DIN EN 1092-2/B nominal diameter 65 mm Pressure range 0 - 16 bar Electrical outlet form A built-in rectifier kV value 72 m³/h Temp.medium -20 to +90°C Temp. environment -20°C to +50°C voltage 120 V frequency 40 - 60 Hz Protection type IP 65 Aufn.Suit 89 VA recording operation 89 VA Resting period 100% Electromagnet installation method vertically upwards Wst.housing nodular cast iron Wst.gasket NBR Switching function. closed in rest position Additional information The delivery includes product information is attached. This product contains wear and tear share them depending on the use, are subject to wear and tear. Perm. /Modest. CE 0045 acc. to Category II PED EAC |
Discover the superior quality and performance of the Buschjost 8648800.9504.12049 with Onrion LLC in Argentina . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 8648800.9504.12049 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 8648800.9504.12049 :
At Onrion LLC , we offer the 8648800.9504.12049 at competitive prices and with the fastest delivery times across Argentina . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 8648800.9504.12049 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Buschjost products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Magnetventil
solenoid valve(230V 50-60Hz 7W PA:0,1-12 bar 4213)
valve
2/2-Wege Magnetventil
Bobini: Parts No: 8240401.9101 205 volts AC 8 Watt ED 100%
(2/2-way solenoid valve)
(2/2-way solenoid valve)
valve Body
82 540 2/2 way
(Tariff 84818079 1.045 kg net price series 82540 Mark 2/2-way solenoid valve Type diaphragm valve Control force pilot, G 3/4 Nominal diameter 20 mm Pressure range 0-16 bar elektr.Ausst. Connector Form A built-in rectifier kv-value 5.80 m³ / h Temp.Medium -10 to + 90 ° C Temp.Umgebung -10 to + 50 ° C voltage 230V frequency 40-60Hz Protection type IP 65 Aufn.Anzug 20 VA Aufn.Betrieb 20 VA Einsch.Dauer 100%)
(Mark 2/2-way solenoid valveType diaphragm valveControl force pilotConnection G 1 1/4Nominal diameter 32 mmPressure range 0-16 barkv-value 23 m³ / hTemp.Medium -10 to + 80 ° CTemp.Umgebung -10 to + 40 ° Cvoltage 230Vfrequency 40-60HzProtection type EEx me II T3, IP 65Ex II 2 GD T 140 ° Celektr.Anschl connection housing for cable 5-10 mmCable entry M16 x 1.5Aufn.Betrieb 195 mAEinsch.Dauer 100%Installation method required, preferably with solenoidvertically upwardsWst.Gehäuse steelWst.Dichtung NBR-K)
2/2-way solenoid valve
2/2-way solenoid valve
110V ac, 10 HAMPERS Reperaturkit (diaphragm + bow) with nominal diameter DN40
2/2-way filter solenoid valve
SELENOID VALVE 1 "
diaphragm valve
2/2-way solenoid valve filter
valve coil
[Twist-on magnet completely; Description: 24V; Medium temp = 100C; Temp environment: -20 to 85 degrees Celsium; cCSAus - Surroundings: 65 degrees Celsium; Voltage: 24V; Frequency: 00 Hz Protection - type: IP 65 / IP 00 connector; Rec. Suit: 12 W; Rec. Operating: 12W; Magnet with CSA Approval ACCORDING TO C / U.S. standards]
Twist magnet complete
Customs tariff 84818079 1.140 kg Description Twist-on magnet completely Description 24V = Temp.Medium 100 ° C. Temp.Umgebung -20 to +85 ° C cCSAus envi. 65 ° C. voltage 24V frequency 00Hz Protection class IP 00 IP 65/Anschluss Aufn.Anzug 8 W Aufn.Betrieb 8 W Additional Info magnet with CSA Approval in accordance C / U.S. standards
