Typ 2,2D2(Ex)dMR7-3(200,24h6x50) - Planetroll Argentina Sales

BRAND	Planetroll
Product	Typ 2,2D2(Ex)dMR7-3(200,24h6x50)
Description	mechanical speed reducer
Internal code	ONR4514268
Custom code	8501 52 20
Technical specification	consisting of: --------------------- a) Three-phase motor "IE3" b) Control gear "p l a r o m a s t e r" Technical specifications ------------------------ Control element: right Design: B14 (motor terminal box on the left) Installation position: 4 (V1) Speed range: 0 to approx. 1200 rpm (50 Hz mains) Output torque: approx. 20 Nm from 20 to 715 rpm ATEX version: Ex II 2G Ex h IIB T4 Gb (drive unit) ================================================== == drive components ------------------------------- 1 PIECE drive side three-phase motor 2.2 kW, 2850 rpm, 230/400 V, 50 Hz, IE3, IP 55, Insulation class F, II 2G Ex db eb IIC T4 Gb, PTC thermistor, BG 90, B5/V1-200 with protective cover. 302-040262 1 PC Control gear plaromaster type MR7 on the drive side: for motor mounting BG 90, B5-200 output side: with B14 flange Ø200, output shaft: Ø24h6 x 50 302-038793 1 PC Control element type: HVK 6, hand wheel (d0=70) with fine adjustment scale coarse scale 0 - 12, fine scale 0 - 100 4 1 PCS + Paint RAL 3004 - purple -

Please Contact Us to Order to offer competitive prices and delivery time for Planetroll - Typ 2,2D2(Ex)dMR7-3(200,24h6x50) mechanical speed reducer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Argentina Industrial products Market.
